The CB signal frame displays, in real time, the CB code number of the vehicle that communicates with the call center at particular time. The number indication in the frame, changes every time a different vehicle is transmitting. In the example below, the car 130 (cb number) is under communication with the call center.
When communications are muted or there are no vehicle transmissions, the number indication is replaced by dashes. The empty frame also signifies that a UHF communication is not established or enabled.
CB Communication Table
By clicking on the CB frame, the CB Communication Table appears on the right site. The table stores in rows the communication history of the transmitted signal, sorted from newest to oldest.
The CB Communication Table consist of two columns. The first stores the vehicle's CB number and the second stores the date and time of the specific transmission. The first row displays the latest communication, which is marked in blue during the transmission .
CB identification is possible only if the car base has established and use a radiofrequency communication system, in parallel with the Call Center of IQTaxi Suite.
